3479.030. Gas spring (Spring plunger) MOULD LINE, with hexagon socket
Description:
Spring plungers are used as ejectors, damper pins, fixing and retaining pins in many sectors of the tool-, jig- and fixture-making industries.
Assembly requires the use of special FIBRO insertion t
Spring plungers are used as ejectors, damper pins, fixing and retaining pins in many sectors of the tool-, jig- and fixture-making industries.
Assembly requires the use of special FIBRO insertion t
Log in to view price, availability, and order the product.
Products
Showing 1-10 of 8 items
| SKU | Length | Max. stroke | |
|---|---|---|---|
| 3479.030.00040.010 | 65 mm | 10 mm | |
| 3479.030.00040.020 | 85 mm | 20 mm | |
| 3479.030.00040.030 | 105 mm | 30 mm | |
| 3479.030.00040.040 | 125 mm | 40 mm | |
| 3479.030.00040.050 | 145 mm | 50 mm | |
| 3479.030.00040.060 | 165 mm | 60 mm | |
| 3479.030.00040.070 | 185 mm | 70 mm | |
| 3479.030.00040.080 | 205 mm | 80 mm |
